Figure Quantity Component Changed Description Notes
1 1.00 23-30-0095 Service Motor Assembly
2 1.00 44-66-0155 Motor Mount Plate
3 2.00 05-81-0205 Screw M3 X 6
4 1.00 14-29-0095 Gearcase Assy Svc
5 1.00 23-66-1095
23-66-1096
Electronics Module Assembly
Variable Electronics Switch Assembly
B30A
B30B
6 5.00 06-82-2400 Gearcase Screw
7 4.00 06-82-2395 Pan Head Plastite T8 Torx Screw, M2.6X10Mm
8 1.00 42-70-0055
42-70-0058
replaced with 42700058
Housing Clip
9 1.00 45-24-0095 Forward/Reverse Button
10 1.00 12-20-2400 Service Nameplate Kit
11 1.00 10-15-0955 Warning Label
12 1.00 10-20-0760 Fuel Gauge Label
13 1.00 22-09-0075 Fuel Gauge
14 1.00 31-50-2400 Housing Set Svc
14a 1.00 --- Housing Half - Left
14b 1.00 --- Housing Half - Right
15 1.00 --- Metal Pin
