Figure Quantity Component Changed Description Notes
1 4.00 06-82-2366 M5 x 26.5mm Pan Head St T-25 Torx Screw
3 1.00 45-88-0101 Plastic Gearcase Washer
4 1.00 44-90-1050 3/8" Friction Ring
5 1.00 34-40-1885 3/8" O-Ring
6 1.00 --- 3/8" Square Friction Ring Anvil
7 1.00 02-02-7010 Steel Ball Bearing, 0.219" Diameter
18 1.00 34-40-0067 O-Ring
24 1.00 02-04-0330 Ball Bearing
25 1.00 45-88-3071 Washer
26 1.00 --- Armature
27 1.00 02-04-1930 Ball Bearing, Sl 625Rs
28 1.00 34-60-2493 External Retaining Ring
29 2.00 06-82-2367 M3 x 38mm Pan Head Self-Tapping T10 Torx Screw
30 6.00 06-82-2368 M3.5 x 16mm Pan Head St T-10 Torx Screw
31 1.00 --- Housing Cover - Right Housing Half
32 1.00 06-65-0465 Roller Pin
33 1.00 06-82-2369 M3.5 x 22mm Pan Head St T-10 Torx Screw
35 1.00 --- Housing Support - Left Housing Half
36 1.00 --- Belt Clip
37 1.00 06-82-0130 Belt Clip Screw
38 1.00 42-42-0018 Forward / Reverse Shuttle
46 1.00 14-38-0006 Front Gearcase Assembly With Bushing
47 1.00 14-73-0009 3/8" Square Friction Ring Anvil Assembly
48 1.00 14-30-0018 Impact Assembly
49 1.00 14-20-0099 Electronics Assembly
50 1.00 16-01-2860 Motor Rotor Assembly
51 1.00 31-44-0069 Housing Assembly
52 1.00 45-24-2656 Speed Selector Assembly
53 1.00 42-70-0059 Belt Clip Hook Kit
54 1.00 12-20-2860 Service Nameplate
56 1.00 42-55-2860 Blow Molded Carrying Case
59 1.00 34-60-0011 Retaining Ring
62 1.00 49-16-2861 Rubber Boot
1.00 49-08-4220 Grease, Type J, 1lb
