Figure Quantity Component Changed Description Notes
8 1.00 34-40-0330 O-Ring
11 6.00 05-90-0225 Spring Washer
12 4.00 05-78-5316 #8-36 T20 Torx Taptite Screw
17 1.00 43-34-3000 Blade Backing Flange
18 1.00 44-40-7100 5/8" Blade Flange Nut
19 1.00 40-50-0386 Compression Spring
20 1.00 44-20-0091 Lock Tang
21 1.00 45-04-0031 Shoulder Taptite Screw, M3-0.50
24 4.00 05-88-1255 M4 x 24 T20 Screw
25 1.00 02-40-0621 Ball Bearing
26 1.00 44-86-2800 Bearing Retainer
27 2.00 05-78-0105 Self Tapping Screw, M4 x 10mm T20
28 1.00 05-55-0620 Metric Hex Nut, M5
29 1.00 --- Bevel Pinion Gear
30 1.00 45-88-0406 Washer 10mm x 8.1mm x 1 mm
31 1.00 --- Rotor
32 1.00 02-04-0111 Ball Bearing, 605-2RS
35 1.00 06-82-1087 M3 x 12 Screw
37 5.00 06-82-2025 Handle Screw
38 1.00 --- Handle Cover
39 1.00 --- Handle Support
43 1.00 40-50-0243 Compression Spring
45 1.00 31-15-0103 Dust Filter Cover
47 1.00 42-62-0125 Avs Side Handle
48 1.00 43-54-1221 5" Blade Guard, Type 27 For Ul
48 1.00 43-54-4010 Plastic Blade Guard Attachment
48 1.00 43-54-1230 5" Blade Guard, Type 1
48 1.00 43-54-1200 4.5" T27 Blade Guard Assembly, Stamped
48 1.00 43-54-1210 4.5" T1 Blade Guard Stamping Assembly
50 1.00 49-96-7215 Spanner Wrench
53 1.00 14-73-2000 5/8" Spindle Hub Assembly
54 1.00 14-20-5030 Electronics Assembly L64A Only
54 1.00 14-20-0446 * Electronics Assembly L65B Only
55 1.00 14-38-2600 Housing Kit L64A Only
55 1.00 14-38-0095 * Housing Kit L65B Only
56 1.00 14-30-1110 Gearcase Assembly
57 1.00 23-40-6010 Rotor Assembly
59 1.00 14-62-0300 Bearing Retainer Plate Assy
60 1.00 31-92-1060 Paddle Trigger Assembly With Spring
61 1.00 12-20-0285 Service Nameplate
62 1.00 50-55-3560 Contractor Bag
63 1.00 --- Rapid Stop Plate
1.00 49-08-4220 Grease, Type J, 1Lb
