Figure Quantity Component Changed Description Notes
8 1.00 34-40-0330 O Ring
11 6.00 05-90-0225 Spring Washer
12 4.00 05-78-5316 #8-36 T20 Torx Taptite Screw
17 1.00 43-34-3000 Blade Backing Flange
18 1.00 44-40-7100 5/8" Blade Flange Nut
19 1.00 40-50-0386 Compression Spring
20 1.00 44-20-0091 Lock Tang
21 1.00 45-04-0031 Shoulder Taptite Screw, M3-0.50
24 4.00 05-88-1255 M4 x 24mm T20 Screw
25 1.00 02-40-0621 Ball Bearing
26 1.00 44-86-2800 Bearing Retainer
27 2.00 05-78-0105 Screw Self Tapping M4 x 10mm T20 Screw
28 1.00 05-55-0620 Metric Hex Nut, M5
29 1.00 --- Bevel Pinion
30 1.00 45-88-0406 Washer 10Mm x 8.1mm x 1 mm
31 1.00 --- Rotor
32 1.00 02-04-0111 Ball Bearing, 605-2RS
35 1.00 06-82-1087 M3 x 12 Screw
37 5.00 06-82-2025 Handle Screw
38 1.00 42-42-0147 Lock-On Button
39 1.00 40-50-0217 Spring For Switch
40 1.00 31-92-0226 Slide Pole
41 1.00 --- Handle Cover
42 1.00 --- Handle Support
43 1.00 31-15-0103 Dust Filter Cover
45 1.00 42-62-0125 AVS Side Handle
46 1.00 43-54-1221 5" Blade Guard, Type 27 For Ul
1.00 43-54-4010 Plastic Blade Guard Attachment
1.00 43-54-1230 5" Blade Guard, Type 1
1.00 43-54-1200 4.5" T27 Blade Guard Assembly, Stamped
1.00 43-54-1210 4.5" T1 Blade Guard Stamping Assembly
48 1.00 49-96-7215 Spanner Wrench
53 1.00 14-73-2000 5/8" Spindle Hub Assembly
54 1.00 14-20-5031 Electronics Assembly
55 1.00 14-38-2601 Housing Kit
56 1.00 14-30-1110 Gearcase Assembly
57 1.00 23-40-6010 Rotor Assembly
59 1.00 14-62-0300 Bearing Retainer Plate Assy
61 1.00 12-20-0285 Service Nameplate
62 1.00 50-55-3560 Contractor Bag
1.00 49-08-4220 Grease, Type J, 1Lb
